Alternator for FORD Focus C-Max (DM2) 1.6 TDCi 80 KW 10.2003
-
Article №: 4G0039 RIDEX Alternator 120A, 14VCar parts maker: RIDEXSuitable for FORD Focus C-Max (DM2) 1.6 TDCi (80 KW / 109 HP / from 2003)
- Alternator Charging Current [A]: 120
- Voltage [V]: 14
- Rated Voltage [V]: 14
- Belt Pulley Ø [mm]: 54
- Pulleys: with freewheel belt pulley
- Number of grooves: 6
- Vehicle Main Current: for vehicles with 12V main current
- Rotation Direction: Clockwise rotation
- Alternator Type: excl. vacuum pump
- Fastening Type: Double Pivot Lever
- Recommended additional repairs: V-Belt/V-Ribbed Belt
- Clamp: B+(M8), SIG, FR, A
- Bore Diameter 1 [mm]: 10
- Number of mounting bores: 4
- Number of threaded holes: 2
- Thread Size: M10
- Distance from belt pulley to alternator [mm]: 42,5
- TecDoc Engine Number: G8DA, G8DB
- Condition: New
OEM: -
Article №: 4G0003 RIDEX Alternator 150A, 12VCar parts maker: RIDEXSuitable for FORD Focus C-Max (DM2) 1.6 TDCi (80 KW / 109 HP / from 2003)
- Alternator Charging Current [A]: 150
- Voltage [V]: 12
- Rated Voltage [V]: 14
- Belt Pulley Ø [mm]: 54
- Pulleys: with freewheel belt pulley
- Number of grooves: 6
- Vehicle Main Current: for vehicles with 12V main current
- Rotation Direction: Clockwise rotation
- Alternator Type: excl. vacuum pump
- Fastening Type: Double Pivot Lever
- Clamp: M8 B+
- Bore Diameter 1 [mm]: 10,4
- Manufacturer Restriction: DENSO
- Number of mounting bores: 4
- Number of threaded holes: 2
- Distance from belt pulley to alternator [mm]: 42,5
- Condition: New
OEM: -
Article №: 4G0796 RIDEX Alternator 70A, 12V, with integrated regulatorCar parts maker: RIDEXSuitable for FORD Focus C-Max (DM2) 1.6 TDCi (80 KW / 109 HP / from 2003)
- Alternator Charging Current [A]: 70
- Voltage [V]: 12
- Rated Voltage [V]: 14
- Belt Pulley Ø [mm]: 52
- Pulleys: with belt pulley, with multi-belt pulley
- Number of grooves: 6
- Supplementary Article / Supplementary Info: with integrated regulator
- Vehicle Main Current: for vehicles with 12V main current
- Rotation Direction: Clockwise rotation
- Alternator Type: excl. vacuum pump
- Fastening Type: Double Pivot Lever
- Clamp: B+(M6),L,DF
- Bore Diameter 1 [mm]: 11
- Number of threaded holes0
- Condition: New
OEM:
-
Article №: CQ1010347 LAUBER Alternator Regulator 12, 14VCar parts maker: LAUBERSuitable for FORD Focus C-Max (DM2) 1.6 TDCi (80 KW / 109 HP / from 2003)
- Construction Year from: 11/2004
- Construction Year to: 02/2007
- Engine Code: G8DA/B
- Transmission Code: CVT,MTX75/5
- Transmission Type: Manual Transmission, CVT automatic transmission (stepless)
- Voltage [V]: 12, 14
- Number of ribs: 6
- Belt Pulley Ø [mm]: 54,5
- Exchange Part
- Control Unit ID: PL57
- Condition: New
OEM: -
Article №: CQ1011337 LAUBER Alternator Regulator 12VCar parts maker: LAUBERSuitable for FORD Focus C-Max (DM2) 1.6 TDCi (80 KW / 109 HP / from 2003)
- Length [mm]: 42,5, 21
- Length 3 [mm]: 45,5
- Voltage [V]: 12
- Alternator Charging Current [A]: 150
- Condition: New
OEM:
-
Article №: 11441383 ALANKO Alternator 35A, 12VCar parts maker: ALANKOSuitable for FORD Focus C-Max (DM2) 1.6 TDCi (80 KW / 109 HP / from 2003)
- Alternator Charging Current [A]: 35
- Voltage [V]: 12
- Pulleys: with belt pulley
- Exchange Part
- Rotation Direction: Clockwise rotation
- Quantity Unit: Piece
- Condition: Remanufactured
OEM: -
Article №: 11443193 ALANKO Alternator 120A, 12, 14V, 6Car parts maker: ALANKOSuitable for FORD Focus C-Max (DM2) 1.6 TDCi (80 KW / 109 HP / from 2003)
- Alternator Charging Current [A]: 120
- Voltage [V]: 12, 14
- Belt Pulley Ø [mm]: 54
- Pulleys: with freewheel belt pulley
- Number of ribs: 6
- Plug Type ID: PLUG138
- Exchange Part
- Quantity Unit: Piece
- Condition: Remanufactured
OEM: -
Article №: 10441383 ALANKO Alternator 35A, 12VCar parts maker: ALANKOSuitable for FORD Focus C-Max (DM2) 1.6 TDCi (80 KW / 109 HP / from 2003)
- Alternator Charging Current [A]: 35
- Voltage [V]: 12
- Pulleys: with belt pulley
- Rotation Direction: Clockwise rotation
- New Part
- Quantity Unit: Piece
- Condition: New
OEM:
-
Article №: RIV600250 RIVOLV AlternatorCar parts maker: RIVOLVSuitable for FORD Focus C-Max (DM2) 1.6 TDCi (80 KW / 109 HP / from 2003)Core exchange £ 7,50 core charge (incl. 20% VAT) is NOT included
The core charge will be refunded if you return the old spare part.
- Belt Pulley Ø [mm]: 54
- Pulleys: with freewheel belt pulley
- Number of grooves: 6
- Rotation Direction: Clockwise rotation
- Recommended additional repairs: V-Belt/V-Ribbed Belt
- Diameter [mm]: 98
- Filter type: Spin-on Filter
- Height [mm]: 180
- Diameter 3 [mm]: 61
- TecDoc Engine Number: G8DA, G8DB
- Condition: New
OEM: -
Article №: RIV600395 RIVOLV Alternator 12VCar parts maker: RIVOLVSuitable for FORD Focus C-Max (DM2) 1.6 TDCi (80 KW / 109 HP / from 2003)Core exchange £ 7,50 core charge (incl. 20% VAT) is NOT included
The core charge will be refunded if you return the old spare part.
- Voltage [V]: 12
- Belt Pulley Ø [mm]: 54
- Number of grooves: 6
- Rotation Direction: Clockwise rotation
- Recommended additional repairs: V-Belt/V-Ribbed Belt
- Filter type: Pollen Filter
- Length [mm]: 454
- TecDoc Engine Number: G8DA, G8DB
- Condition: New
OEM:
-
Article №: A4035SR AS-PL Alternator 80A, 12VCar parts maker: AS-PLSuitable for FORD Focus C-Max (DM2) 1.6 TDCi (80 KW / 109 HP / from 2003)
- Alternator Charging Current [A]: 80
- Voltage [V]: 12
- Pulleys: with belt pulley
- Length 3 [mm]: 54,00
- Length [mm]: 12,00, 40,00
- Condition: Remanufactured
OEM: -
Article №: A4035PR AS-PL Alternator 80A, 12VCar parts maker: AS-PLSuitable for FORD Focus C-Max (DM2) 1.6 TDCi (80 KW / 109 HP / from 2003)
- Alternator Charging Current [A]: 80
- Voltage [V]: 12
- Pulleys: with belt pulley
- Manufacturer Restriction: MAGNETI MARELLI
- Quality: PREMIUM LINE
- Exchange Part without deposit
- Condition: Remanufactured
OEM: -
Article №: A6190PR AS-PL Alternator 105A, 12VCar parts maker: AS-PLSuitable for FORD Focus C-Max (DM2) 1.6 TDCi (80 KW / 109 HP / from 2003)
- Alternator Charging Current [A]: 105
- Voltage [V]: 12
- Pulleys: with belt pulley
- Manufacturer Restriction: DENSO
- Quality: PREMIUM LINE
- Exchange Part without deposit
- Condition: Remanufactured
OEM:
-
Article №: 4G0796R RIDEX REMAN Alternator 70A, 12V, with integrated regulatorCar parts maker: RIDEX REMANSuitable for FORD Focus C-Max (DM2) 1.6 TDCi (80 KW / 109 HP / from 2003)Core exchange £ 30,92 core charge (incl. 20% VAT) is NOT included
The core charge will be refunded if you return the old spare part.
- Alternator Charging Current [A]: 70
- Voltage [V]: 12
- Rated Voltage [V]: 14
- Belt Pulley Ø [mm]: 52
- Pulleys: with belt pulley, with multi-belt pulley
- Number of grooves: 6
- Supplementary Article / Supplementary Info: with integrated regulator
- Vehicle Main Current: for vehicles with 12V main current
- Rotation Direction: Clockwise rotation
- Alternator Type: excl. vacuum pump
- Fastening Type: Double Pivot Lever
- Clamp: B+(M6),L,DF
- Bore Diameter 1 [mm]: 11
- Number of threaded holes0
- Condition: Remanufactured
OEM: -
Article №: 4G0039R RIDEX REMAN Alternator 120A, 14VCar parts maker: RIDEX REMANSuitable for FORD Focus C-Max (DM2) 1.6 TDCi (80 KW / 109 HP / from 2003)Core exchange £ 36,07 core charge (incl. 20% VAT) is NOT included
The core charge will be refunded if you return the old spare part.
- Alternator Charging Current [A]: 120
- Voltage [V]: 14
- Rated Voltage [V]: 14
- Belt Pulley Ø [mm]: 54
- Pulleys: with freewheel belt pulley
- Number of grooves: 6
- Vehicle Main Current: for vehicles with 12V main current
- Rotation Direction: Clockwise rotation
- Alternator Type: excl. vacuum pump
- Fastening Type: Double Pivot Lever
- Recommended additional repairs: V-Belt/V-Ribbed Belt
- Clamp: B+(M8), SIG, FR, A
- Bore Diameter 1 [mm]: 10
- Number of mounting bores: 4
- Number of threaded holes: 2
- Thread Size: M10
- Distance from belt pulley to alternator [mm]: 42,5
- TecDoc Engine Number: G8DA, G8DB
- Condition: Remanufactured
OEM:
