Alternator for VAUXHALL Astra Mk4 (G) CC (T98) 2.0 DTI 16V (F48) 74 KW 08.1999
-
Article №: 4G0236 RIDEX Alternator 100A, 12VCar parts maker: RIDEXSuitable for VAUXHALL Astra Mk IV (G) CC (T98) 2.0 DTI 16V (F48) (74 KW / 101 HP / from 1999)
- Alternator Charging Current [A]: 100
- Voltage [V]: 12
- Rated Voltage [V]: 14
- Engine Code: X20DTH
- Belt Pulley Ø [mm]: 49
- Pulleys: with belt pulley
- Number of grooves: 6
- Vehicle Main Current: for vehicles with 12V main current
- Rotation Direction: Clockwise rotation
- Alternator Type: excl. vacuum pump
- Connector/Clamp: without connection for speed sensor
- Fastening Type: Double Pivot Lever
- Clamp: B+(M8),D+(M5)
- Bore Diameter 1 [mm]: 10
- Number of threaded holes0
- Distance from belt pulley to alternator [mm]: 51,1
- Condition: New
OEM: -
Article №: 4G0299 RIDEX Alternator 70A, 12VCar parts maker: RIDEXSuitable for VAUXHALL Astra Mk IV (G) CC (T98) 2.0 DTI 16V (F48) (74 KW / 101 HP / from 1999)
- Alternator Charging Current [A]: 70
- Voltage [V]: 12
- Rated Voltage [V]: 14
- Belt Pulley Ø [mm]: 54
- Pulleys: with V-ribbed belt pulley, V-Ribbed Belt Pulley
- Number of grooves: 5
- Vehicle Main Current: for vehicles with 12V main current
- Rotation Direction: Clockwise rotation
- Alternator Type: excl. vacuum pump
- Fastening Type: Double Pivot Lever
- Clamp: B+(M8),D+(M5)
- Bore Diameter 1 [mm]: 10
- Bore Diameter 2 [mm]: 10
- Number of mounting bores: 4
- Number of threaded holes: 2
- Thread Size: M10
- Distance from belt pulley to alternator [mm]: 54,6
- Condition: New
OEM: -
Article №: 4G0063 RIDEX Alternator 120A, 14VCar parts maker: RIDEXSuitable for VAUXHALL Astra Mk IV (G) CC (T98) 2.0 DTI 16V (F48) (74 KW / 101 HP / from 1999)
- Alternator Charging Current [A]: 120
- Voltage [V]: 14
- Rated Voltage [V]: 14
- Belt Pulley Ø [mm]: 50
- Pulleys: with belt pulley
- Number of grooves: 6
- Vehicle Main Current: for vehicles with 12V main current
- Rotation Direction: Clockwise rotation
- Alternator Type: excl. vacuum pump
- Fastening Type: Double Pivot Lever
- Clamp: B+(M8),D+(M5)
- Bore Diameter 1 [mm]: 10
- Number of mounting bores: 4
- Number of threaded holes0
- Distance from belt pulley to alternator [mm]: 51
- Condition: New
OEM:
-
Article №: 135.510.070.216 BV PSH Alternator 70A, 12VCar parts maker: BV PSHSuitable for VAUXHALL Astra Mk IV (G) CC (T98) 2.0 DTI 16V (F48) (74 KW / 101 HP / from 1999)
- Alternator Charging Current [A]: 70
- Voltage [V]: 12
- Belt Pulley Ø [mm]: 56,0
- Number of grooves: 6
- Clamp: B+ (M8)
- Quality: Bosch Reman
- Number of mounting bores: 4
- Mounting Angle [degrees]: +60
- Condition: New
OEM: -
Article №: 135.510.100.038 BV PSH Alternator 100A, 12VCar parts maker: BV PSHSuitable for VAUXHALL Astra Mk IV (G) CC (T98) 2.0 DTI 16V (F48) (74 KW / 101 HP / from 1999)
- Alternator Charging Current [A]: 100
- Voltage [V]: 12
- Belt Pulley Ø [mm]: 56,0
- Number of grooves: 6
- Clamp: B+ (M8)
- Quality: RNL-Standard
- Number of mounting bores: 2
- Mounting Angle [degrees]: +60
- Condition: New
OEM: -
Article №: 135.510.070.506 BV PSH Alternator 70A, 12VCar parts maker: BV PSHSuitable for VAUXHALL Astra Mk IV (G) CC (T98) 2.0 DTI 16V (F48) (74 KW / 101 HP / from 1999)
- Alternator Charging Current [A]: 70
- Voltage [V]: 12
- Clamp: B+
- Quality: Valeo Reman
- Condition: New
OEM: -
Article №: 135.507.100.395 BV PSH Alternator 100A, 12VCar parts maker: BV PSHSuitable for VAUXHALL Astra Mk IV (G) CC (T98) 2.0 DTI 16V (F48) (74 KW / 101 HP / from 1999)
- Alternator Charging Current [A]: 100
- Voltage [V]: 12
- Belt Pulley Ø [mm]: 50,0
- Number of grooves: 6
- Clamp: B+ (M8)
- Quality: Remy Reman
- Number of mounting bores: 4
- Condition: New
OEM: -
Article №: 135.510.100.010 BV PSH Alternator 100A, 12VCar parts maker: BV PSHSuitable for VAUXHALL Astra Mk IV (G) CC (T98) 2.0 DTI 16V (F48) (74 KW / 101 HP / from 1999)
- Construction Year from: 09/2000
- usable for vehicles with alternator charging current [A]: 100
- Alternator Charging Current [A]: 100
- Voltage [V]: 12
- Belt Pulley Ø [mm]: 49,3
- Number of grooves: 6
- Clamp: B+ (M8)
- Quality: +Line
- Number of mounting bores: 4
- Mounting Angle [degrees]: +60
- Condition: New
OEM: -
Article №: 135.511.120.215 BV PSH Alternator 120A, 12VCar parts maker: BV PSHSuitable for VAUXHALL Astra Mk IV (G) CC (T98) 2.0 DTI 16V (F48) (74 KW / 101 HP / from 1999)
- New Part
- Manufacturer Restriction: BOSCH
- usable for vehicles with alternator charging current [A]: 100
- Alternator Charging Current [A]: 120
- Voltage [V]: 12
- Belt Pulley Ø [mm]: 49,0
- Number of grooves: 6
- Clamp: B+ (M8)
- Quality: Bosch Reman
- Number of mounting bores: 4
- Mounting Angle [degrees]: +60
- Condition: New
OEM: -
Article №: 135.510.100.216 BV PSH Alternator 100A, 12VCar parts maker: BV PSHSuitable for VAUXHALL Astra Mk IV (G) CC (T98) 2.0 DTI 16V (F48) (74 KW / 101 HP / from 1999)
- Alternator Charging Current [A]: 100
- Voltage [V]: 12
- Belt Pulley Ø [mm]: 49,0
- Number of grooves: 6
- Clamp: B+ (M8)
- Quality: Bosch Reman
- Number of mounting bores: 4
- Mounting Angle [degrees]: +60
- Condition: New
OEM:
-
Article №: DRA3704N DELCO REMY Alternator 100A, 12V, with integrated regulator, 6Car parts maker: DELCO REMYSuitable for VAUXHALL Astra Mk IV (G) CC (T98) 2.0 DTI 16V (F48) (74 KW / 101 HP / from 1999)
- Construction Year from: 09/2000
- usable for vehicles with alternator charging current [A]: 100
- Manufacturer Restriction: BOS
- Alternator Charging Current [A]: 100
- Voltage [V]: 12
- Belt Pulley Ø [mm]: 55
- Pulleys: with V-ribbed belt pulley
- Number of ribs: 6
- Plug Type ID: Plug381
- Supplementary Article / Supplementary Info: with integrated regulator
- Used part return not required
- Length [mm]: 34.0 / 55.0, 18
- Similar to picture
- Condition: New
OEM: -
Article №: DRB2750 DELCO REMY Alternator Remy Remanufactured, 100A, 12V, with integrated regulator, 6Car parts maker: DELCO REMYSuitable for VAUXHALL Astra Mk IV (G) CC (T98) 2.0 DTI 16V (F48) (74 KW / 101 HP / from 1999)Core exchange £ 35,00 core charge (incl. 20% VAT) is NOT included
The core charge will be refunded if you return the old spare part.
- Construction Year from: 09/2000
- usable for vehicles with alternator charging current [A]: 100
- Alternator Charging Current [A]: 100
- Voltage [V]: 12
- Belt Pulley Ø [mm]: 50
- Pulleys: with V-ribbed belt pulley
- Number of ribs: 6
- Supplementary Info: Remy Remanufactured
- Plug Type ID: Plug381
- Supplementary Article / Supplementary Info: with integrated regulator
- Weight [kg]: 5,5
- Used part return required
- Similar to picture
- Condition: Remanufactured
OEM:
-
Article №: STX101450 STARDAX Alternator 120A, 14VCar parts maker: STARDAXSuitable for VAUXHALL Astra Mk IV (G) CC (T98) 2.0 DTI 16V (F48) (74 KW / 101 HP / from 1999)
- Construction Year from: 09/2000
- TecDoc Engine Number: Y 20 DTH
- Alternator Charging Current [A]: 120
- Voltage [V]: 14
- Belt Pulley Ø [mm]: 50
- Pulleys: with belt pulley
- Condition: New
OEM:
-
Article №: A1010 AS-PL Alternator 100A, 12VCar parts maker: AS-PLSuitable for VAUXHALL Astra Mk IV (G) CC (T98) 2.0 DTI 16V (F48) (74 KW / 101 HP / from 1999)
- Alternator Charging Current [A]: 100
- Voltage [V]: 12
- Pulleys: with belt pulley
- Quality: STANDARD LINE
- New part without deposit
- Condition: New
OEM:
-
Article №: RIV600163 RIVOLV Alternator 120A, 12VCar parts maker: RIVOLVSuitable for VAUXHALL Astra Mk IV (G) CC (T98) 2.0 DTI 16V (F48) (74 KW / 101 HP / from 1999)Core exchange £ 7,51 core charge (incl. 20% VAT) is NOT included
The core charge will be refunded if you return the old spare part.
- Construction Year from: 09/2000
- Vehicle Equipment: for vehicles without electr. auxiliary heater
- Alternator Charging Current [A]: 120
- Voltage [V]: 12
- Belt Pulley Ø [mm]: 49,6
- Pulleys: with multi-belt pulley
- Number of grooves: 6
- Exchange Part
- Rotation Direction: Clockwise rotation
- Fastening Type: Double Pivot Lever
- Recommended additional repairs: V-Belt/V-Ribbed Belt
- Condition: New
OEM:
